Ang serye ng WFB na hindi self-priming pump na pump ay nagpatibay ng isang "interlocking" multi-sided centrifugal sealing aparato, na walang "tumatakbo, bumubulusok, tumutulo, tumagas" na pag-aalala. Dahil walang alitan ng sealing aparato at walang pagsusuot sa panahon ng operasyon, ang buhay ng serbisyo ay maraming beses na mas mahaba kaysa sa mga katulad na produkto. Ang bomba ay may paglaban sa temperatura, paglaban sa presyon, lumalaban sa pagsusuot ng "isang kanal, panghabambuhay na pag-priming" at iba pang mga pag-andar, maaasahan ang pagganap ng sarili, lalo na ang paggamit ng isang "electric air valve valve" na may maaasahang operasyon, madaling i-disassemble, madaling i-install at iba pa. Ang bomba ay gawa sa hindi kinakalawang na asero, pinalakas na polyurethane, cast steel, at iba pang mga materyales, na may mababang panginginig ng boses, mababang ingay, at madaling pag -disassembly. Malawakang ginagamit ito sa electronics, electric power, kemikal na industriya, metalurhiya, gamot, pagkain, electroplating, proteksyon sa kapaligiran, consumer, munisipal, paglilinis ng tubig, pambansang pagtatanggol, at industriya ng militar, pag -print ng tela at pagtitina, pag -aalaga at pagproseso ng mineral, konstruksyon ng sibil, at iba pang mga industriya, at mahusay na natanggap ng mga gumagamit.
| Model | Umiikot bilis n r/min | Daloy Q m³/h | Kabuuan iangat H m | Pagpapahiwatig ng motor | Pinapayagan pagsipsip lalim ≤m | Pagsipsip nanganak mm | Pakawalan nanganak mm | Timbang kg | ||
| Model | KW | V | ||||||||
| 16wfb-a | 2900 | 0.75 | 8 | Y2-80M1-2 | 0.75 | 380 | 2.5 | 16 | 10 | 75 |
| 1.1 | 6.5 | |||||||||
| 1.5 | 5.5 | |||||||||
| 25wfb-a | 2900 | 3.6 | 25 | Y2-100L-2 | 3 | 380 | 3.5 | 25 | 20 | 110 |
| 32WFB-A | 2900 | 4.5 | 13 | Y2-90S-2 | 1.5 | 380 | 3 | 32 | 25 | 99 |
| 6.5 | 10.5 | |||||||||
| 9 | 8 | |||||||||
| 40WFB-A | 2900 | 6.5 | 25 | Y2-112M-2 | 4 | 380 | 4 | 40 | 32 | 140 |
| 8.5 | 23 | |||||||||
| 10 | 21 | |||||||||
| 40WFB-A | 2900 | 13.5 | 18 | Y2-100L-2 | 3 | 380 | 4 | 40 | 0o U | 140 |
| 40WFB-A₂ | 2900 | 5 | 15 | Y2-90L-2 | 2.2 | 380 | 4 | 40 | 32 | 125 |
| 8 | 13 | |||||||||
| 10 | 11 | |||||||||
| 40WFB-A₃ | 2900 | 14 | 8 | Y2-90L-2 | 2.2 | 380 | 4 | 40 | 32 | 125 |
| 50wfb-A | 2900 | 7.5 | 28 | Y2-132S1-2 | 5.5 | 380 | 5 | 50 | 40 | 205 |
| 12.5 | 26 | |||||||||
| 15 | 24.5 | |||||||||
| 50WFB-A, | 2900 | 10.5 | 20.5 | Y2-100L-2 | 3 | 380 | 5 | 50 | 40 | 170 |
| 50WFB-AD | 1450 | 5 | 11 | Y2-90S-2 | 1.5 | 380 | 4 | 50 | 40 | 149 |
| 6.3 | 10 | |||||||||
| 7.5 | 9 | |||||||||
| 50WFB-AD | 1450 | 10 | 6 | Y2-90S-2 | 1.5 | 380 | 4 | 50 | 40 | 149 |
| 50WFB-B | 2900 | 10 | 40 | Y2-160M1-2 | 11 | 380 | 5 | 50 | 40 | 215 |
| 11 | 38 | |||||||||
| 15 | 35 | |||||||||
| 50WFB- | 2900 | 7 | 33 | Y2-132S2-2 | 7.5 | 380 | 5 | 50 | 40 | 205 |
| 12 | 31 | |||||||||
| 15 | 29 | |||||||||
| 50WFB-B | 2900 | 10 | 26.5 | Y2-112M-2 | 4 | 380 | 5 | 50 | 40 | 185 |
| 50WFB-B | 2900 | 5 | 15 | Y2-90L-2 | 2.2 | 380 | 4 | 50 | 40 | 150 |
| 6.4 | 14 | |||||||||
| 7.5 | 12.5 | |||||||||
| 50WFB-C | 2900 | 8.5 | 58 | Y2-160M2-2 | 7.5 | 380 | 5 | 50 | 40 | 240 |
| 12 | 56 | |||||||||
| 15 | 54 | |||||||||
| 50WFB-C | 2900 | 10 | 46 | Y2-160M1-2 | 15 | 380 | 5 | 50 | 40 | 215 |
| 12 | 40 | |||||||||
| 50WFB-CD | 1450 | 5 | 19 | Y2-100L-2 | 3 | 380 | 4 | 50 | 40 | 170 |
| 6 | 18 | |||||||||
| 8 | 17 | |||||||||
| 50wfb-e | 2900 | 7.5 | 85 | Y2-180M-2 | 18.5 | 380 | 5 | 50 | 40 | 260 |
| 12 | 80 | |||||||||
| 15 | 75 | |||||||||
| 50wfb-e | 2900 | 10 | 68 | Y2-160L-2 | 15 | 380 | 5 | 50 | 40 | 250 |
| 12 | 62 | |||||||||
| 15 | 55 | |||||||||
| 50WFB-E₂ | 2900 | 3.5 | 26 | Y2-112M-2 | 3 | 380 | 4 | 50 | 40 | 170 |
| 6.3 | 25 | |||||||||
| 7.5 | 24 | |||||||||
| 65wfb-a | 2900 | 15 | 27 | Y2-132S2-2 | 7.5 | 380 | 4 | 65 | 50 | 260 |
| 20 | 26 | |||||||||
| 25 | 24 | |||||||||
| 65wfb-a, | 2900 | 21 | 20 | Y2-132S1-2 | 5.5 | 380 | 4 | 65 | 50 | 260 |
| 65WFB-AD | 1450 | 7 | 12 | Y2-100L-2 | 3 | 380 | 4 | 65 | 50 | 200 |
| 12 | 11 | |||||||||
| 15 | 9 | |||||||||
| 65WFB-B | 2900 | 15 | 41 | Y2-160M1-2 | 11 | 380 | 5 | 65 | 50 | 270 |
| 25 | 38 | |||||||||
| 30 | 34 | |||||||||
| 65WFB-B. | 2900 | 20 | 26 | 7.5 | 80 | 5 | 65 | 50 | 250 | |
| 65WFB-BD | 1450 | 10 | 16 | Y2-132S-2 | 4 | 380 | 5 | 65 | 50 | 230 |
| 12 | 14 | |||||||||
| 15 | 13 | |||||||||
| 65WFB-C | 2900 | 15 | 58 | Y2-160L-2 | 18.5 | 380 | 5 | 65 | 50 | 280 |
| 25 | 56 | |||||||||
| 30 | 52 | |||||||||
| 65WFB-C, | 2900 | 22 | 45 | Y2-160M2-2 | 15 | 380 | 5 | 65 | 50 | 265 |
| 65WFB-C₂ | 2900 | 7.5 | 19 | Y2-112M-2 | 4 | 380 | 5 | 65 | 50 | 240 |
| 12.5 | 18 | |||||||||
| 15 | 17 | |||||||||
| 65wfb-e | 2900 | 15 | 82 | Y2-200L1-2 | 30 | 380 | 5 | 65 | 50 | 450 |
| 25 | 80 | |||||||||
| 30 | 78 | |||||||||
| 65wfb-e, | 2900 | 21 | 64 | Y2-160L-2 | 18.5 | 380 | 5 | 65 | 50 | 340 |
| 20 | 55 | |||||||||
| 65wfb-e₂ | 2900 | 7.5 | 27.5 | Y2-132S2-2 | 7.5 | 380 | 5 | 65 | 50 | 280 |
| 12.5 | 26 | |||||||||
| 15 | 24.5 | |||||||||
| 65wfb-f | 2900 | 15 | 127 | Y2-250M-2 | 45 | 380 | 5 | 65 | 50 | 485 |
| 25 | 125 | |||||||||
| 30 | 123 | |||||||||
| 65wfb-f₁ | 2900 | 18 | 108 | Y2-225M-2 | 45 | 380 | 5 | 65 | 50 | 485 |
| 21.5 | 95 | |||||||||
| 23.5 | 85 | |||||||||
| 65wfb-f₂ | 2900 | 7.5 | 38 | Y2-132S2-2 | 7.5 | 380 | 5 | 65 | 50 | 270 |
| 12.5 | 37 | |||||||||
| 15 | 36 | |||||||||
| 65wfb-f₃ | 2900 | 7 | 34 | Y2-132S1-2 | 5.5 | 380 | 5 | 65 | 50 | 260 |
| 9 | 30 | |||||||||
| 12 | 26 | |||||||||
| 80WFB-A | 2900 | 30 | 28 | Y2-160M1-2 | 11 | 380 | 6 | 80 | 65 | 380 |
| 50 | 26 | |||||||||
| 60 | 24 | |||||||||
| 70 | 20 | |||||||||
| 80WFB-AD | 2900 | 15 | 11.5 | Y2-112M-4 | 4 | 380 | 4 | 80 | 65 | 305 |
| 25 | 11 | |||||||||
| 30 | 10.5 | |||||||||
| 38 | 9 | |||||||||
| 80WFB-B | 2900 | 40 | 40 | Y2-160M2-2 | 15 | 380 | 5 | 80 | 65 | 395 |
| 50 | 38 | |||||||||
| 60 | 35 | |||||||||
| 65 | 28 | |||||||||
| 80WFB-BD | 1450 | 15 | 15 | Y2-132S-4 | 5.5 | 380 | 5 | 80 | 65 | 340 |
| 25 | 14 | |||||||||
| 30 | 13 | |||||||||
| 35 | 11 | |||||||||
| 80WFB-C | 2900 | 30 | 59 | Y2-180M-2 | 22 | 380 | 5 | 80 | 65 | 460 |
| 50 | 55 | |||||||||
| 60 | 52 | |||||||||
| 80WFB-C, | 2900 | 45 | 38 | Y2-160M2-2 | 15 | 380 | 5 | 80 | 65 | 400 |
| 40 | 46 | |||||||||
| 80WFB-C₂ | 2900 | 15 | 19 | Y2-132S2-2 | 7.5 | 380 | 5 | 80 | 65 | 320 |
| 25 | 18 | |||||||||
| 30 | 17 | |||||||||
| 80WFB-CD | 1450 | 21 | 14 | Y2-132S-4 | 5.5 | 380 | 5 | 80 | 65 | 340 |
| 25 | 12 | |||||||||
| 80wfb-e | 2900 | 30 | 84 | Y2-200L2-2 | 37 | 380 | 5 | 80 | 65 | 480 |
| 50 | 80 | |||||||||
| 60 | 76 | |||||||||
| 80wfb-e, | 2900 | 30 | 60 | Y2-160L-2 | 18.5 | 380 | 5 | 80 | 65 | 400 |
| 40 | 50 | |||||||||
| 80WFB-E₂ | 2900 | 15 | 27 | Y2-160M1-2 | 11 | 380 | 5 | 80 | 65 | 380 |
| 25 | 26 | |||||||||
| 30 | 24 | |||||||||
| 80WFB-E₃ | 2900 | 20 | 22 | Y2-132S1-2 | 5.5 | 380 | 5 | 80 | 65 | 300 |
| 22 | 18 | |||||||||
| 80wfb-f | 2900 | 30 | 128 | Y2-250M-2 | 55 | 380 | 5 | 80 | 65 | 580 |
| 50 | 120 | |||||||||
| 60 | 110 | |||||||||
| 80wfb-f, | 2900 | 26 | 103 | Y2-225M-2 | 45 | 380 | 5 | 80 | 65 | 530 |
| 30 | 95 | |||||||||
| 40 | 80 | |||||||||
| 80wfb-f₂ | 2900 | 15 | 38 | Y2-160M1-2 | 11 | 380 | 5 | 80 | 65 | 380 |
| 25 | 36 | |||||||||
| 30 | 35 | |||||||||
| 80wfb-f₃ | 2900 | 21 | 34 | Y2-160M1-2 | 11 | 380 | 5 | 80 | 65 | 380 |
| 23 | 30 | |||||||||
| 26 | 26 | |||||||||
| 100WFB-A | 2900 | 60 | 30 | Y2-180M-2 | 18.5 | 380 | 5 | 100 | 80 | 560 |
| 100 | 26 | |||||||||
| 110 | 22 | |||||||||
| 120 | 20 | |||||||||
| 100WFB-AD | 1450 | 30 | 12 | Y2-132M-4 | 7.5 | 380 | 5 | 100 | 80 | 450 |
| 40 | 11 | |||||||||
| 50 | 10 | |||||||||
| 60 | 9 | |||||||||
| 100WFB-B | 2900 | 60 | 40 | Y2-180M-2 | 22 | 380 | 5 | 100 | 80 | 580 |
| 80 | 36 | |||||||||
| 100 | 32 | |||||||||
| 120 | 28 | |||||||||
| 100WFB-BD | 1450 | 30 | 15 | Y2-160M-4 | 11 | 380 | 5 | 100 | 80 | 520 |
| 40 | 14 | |||||||||
| 50 | 13 | |||||||||
| 68 | 11 | |||||||||
| 100WFB-BD | 1450 | 110 | 16 | Y2-160L-4 | 15 | 380 | 7 | 100 | 80 | 520 |
| 130 | 10 | |||||||||
| 150 | 8 | |||||||||
| 100WFB-C | 2900 | 45 | 55 | Y2-200L2-2 | 37 | 380 | 5 | 100 | 80 | 630 |
| 80 | 48 | |||||||||
| 100 | 45 | |||||||||
| 100WFB-C₁ | 2900 | 75 | 40 | Y2-200L1-2 | 30 | 380 | 5 | 100 | 80 | 605 |
| 85 | 35 | |||||||||
| 100WFB-C₂ | 2900 | 40 | 20 | Y2-160M1-2 | 11 | 380 | 5 | 100 | 80 | 520 |
| 50 | 19 | |||||||||
| 60 | 18 | |||||||||
| 100WFB-C₃ | 2900 | 40 | 16 | Y2-132S2-2 | 7.5 | 380 | 5 | 100 | 80 | 500 |
| 45 | 15 | |||||||||
| 100wfb-e | 2900 | 60 | 87 | Y2-250M-2 | 55 | 380 | 5 | 100 | 80 | 720 |
| 80 | 80 | |||||||||
| 100 | 75 | |||||||||
| 100wfb-e, | 2900 | 80 | 60 | Y2-225M-2 | 45 | 380 | 5 | 100 | 80 | 680 |
| 100 | 51 | |||||||||
| 100wfb-e₂ | 2900 | 30 | 26 | Y2-160M1-2 | 11 | 380 | 5 | 100 | 80 | 530 |
| 50 | 25 | |||||||||
| 55 | 24 | |||||||||
| 100wfb-e₃ | 2900 | 58 | 22 | Y2-160M1-2 | 11 | 380 | 5 | 100 | 80 | 530 |
| 62 | 18 | |||||||||
| 100wfb-f | 2900 | 60 | 133 | Y2-280M-2 | 90 | 380 | 5 | 100 | 80 | 965 |
| 80 | 125 | |||||||||
| 100 | 120 | |||||||||
| 100wfb-f | 2900 | 80 | 108 | Y2-280S-2 | 75 | 380 | 5 | 100 | 80 | 820 |
| 90 | 90 | |||||||||
| 100 | 80 | |||||||||
| 100wfb-f₂ | 2900 | 30 | 40 | Y2-160M2-2 | 15 | 380 | 5 | 100 | 80 | 550 |
| 50 | 38 | |||||||||
| 60 | 36 | |||||||||
| 100wfb-f₃ | 2900 | 40 | 33 | Y2-160M1-2 | 11 | 380 | 5 | 100 | 80 | 530 |
| 43 | 29 | |||||||||
| 46 | 26 | |||||||||
| 125WFB-A | 2900 | 100 | 55 | Y2-250M-2 | 55 | 380 | 5 | 125 | 100 | 900 |
| 150 | 50 | |||||||||
| 180 | 45 | |||||||||
| 125WFB-A₁ | 2900 | 170 | 40 | Y2-225M-2 | 45 | 380 | 5 | 125 | 100 | 860 |
| 185 | 30 | |||||||||
| 125WFB-A₂ | 2900 | 70 | 20 | Y2-160M2-2 | 15 | 380 | 5 | 125 | 100 | 720 |
| 80 | 19 | |||||||||
| 100 | 17 | |||||||||
| 125WFB-AD | 1450 | 105 | 16 | Y2-160L-4 | 15 | 380 | 5 | 125 | 100 | 740 |
| 110 | 15 | |||||||||
| 125WFB-B | 2900 | 120 | 86 | Y2-315S-2 | 110 | 380 | 5 | 125 | 100 | 1150 |
| 180 | 80 | |||||||||
| 220 | 72 | |||||||||
| 125WFB-B, | 2900 | 150 | 65 | Y2-280S-2 | 75 | 380 | 5 | 125 | 100 | 1005 |
| 170 | 60 | |||||||||
| 125WFB-B₂ | 2900 | 80 | 26 | Y2-180M-2 | 22 | 380 | 5 | 125 | 100 | 760 |
| 100 | ||||||||||
| 120 | 24 | |||||||||
| 125WFB-B₂ | 2900 | 85 | 22 | Y2-160L-2 | 18.5 | 380 | 5 | 125 | 100 | 730 |
| 90 | 20 | |||||||||
| 125WFB-C | 2900 | 160 | 132 | Y2-315L1-2 | 160 | 380 | 5 | 125 | 100 | 1580 |
| 180 | 125 | |||||||||
| 200 | 120 | |||||||||
| 125WFB-C₁ | 2900 | 180 | 108 | Y2-315S-2 | 110 | 380 | 5 | 125 | 100 | 1270 |
| 190 | 93 | |||||||||
| 208 | 80 | |||||||||
| 125WFB-C₂ | 2900 | 80 | 40 | Y2-200L1-2 | 30 | 380 | 5 | 125 | 100 | 790 |
| 100 | 38 | |||||||||
| 120 | 36.5 | |||||||||
| 125WFB-C₃ | 2900 | 92 | 23 | Y2-160L-2 | 18.5 | 380 | 5 | 125 | 100 | 750 |
| 85 | 26 | |||||||||
| 80 | 29 | |||||||||
| 125wfb-e | 1450 | 70 | 52 | Y2-200L2-2 | 37 | 380 | 5 | 125 | 100 | 820 |
| 90 | 50 | |||||||||
| 110 | 48 | |||||||||
| 125wfb-e₁ | 2900 | 90 | 45 | Y2-200L1-2 | 30 | 380 | 5 | 125 | 100 | 790 |
| 95 | 40 | |||||||||
| 125wfb-e₂ | 2900 | 85 | 36 | Y2-180M-2 | 22 | 380 | 5 | 125 | 100 | 770 |
| 150WFB-A | 2900 | 120 | 28 | Y2-200L1-2 | 30 | 380 | 5 | 150 | 125 | 990 |
| 185 | 26 | |||||||||
| 200 | 23.5 | |||||||||
| 240 | 22.5 | |||||||||
| 150WFB-AD | 1450 | 160 | 20 | Y2-180L-4 | 22 | 380 | 5 | 150 | 125 | 960 |
| 150WFB-B | 1450 | 156 | 40 | Y2-225M-2 | 45 | 380 | 5 | 150 | 125 | 1060 |
| 180 | 36 | |||||||||
| 225 | 30 | |||||||||
| 150WFB-B₁ | 1450 | 160 | 34 | Y2-200L2-2 | 37 | 380 | 5 | 150 | 125 | 1020 |
| 180 | 29 | |||||||||
| 195 | 26 | |||||||||
| 150WFB-BD | 1450 | 175 | 32 | Y2-225M-4 | 45 | 380 | 5 | 150 | 125 | 1080 |
| 220 | 29 | |||||||||
| 260 | 25 | |||||||||
| 150WFB-BD, | 1450 | 120 | 55 | Y2-280S-4 | 75 | 380 | 5 | 150 | 125 | 1205 |
| 200 | 50 | |||||||||
| 240 | 45 | |||||||||
| 150WFB-C | 1450 | 180 | 45 | Y2-250M-2 | 55 | 380 | 5 | 150 | 125 | 1100 |
| 190 | 38 | |||||||||
| 150WFB-C, | 1450 | 165 | 36 | Y2-250M-2 | 55 | 380 | 5 | 150 | 125 | 1020 |
| 200wfb-ad | 1450 | 250 | 26.5 | Y2-250M-4 | 55 | 380 | 5 | 200 | 150 | 1415 |
| 330 | 25 | |||||||||
| 350 | 23.5 | |||||||||
| 200wfb-ad | 1450 | 300 | 22 | Y2-225M-4 | 45 | 380 | 5 | 200 | 150 | 1375 |
| 200wfb-ad₂ | 1450 | 330 | 19 | Y2-225S-4 | 37 | 380 | 5 | 200 | 150 | 1335 |
| 320 | 15 | |||||||||
| 380 | 10 | |||||||||
| 200wfb-bd | 1450 | 240 | 42 | Y2-280S-4 | 75 | 380 | 5 | 200 | 150 | 1520 |
| 300 | 37 | |||||||||
| 350 | 33.5 | |||||||||
| 200wfb-bd | 1450 | 250 | 28.5 | Y2-250M-4 | 55 | 380 | 5 | 200 | 150 | 1415 |
| 200wfb-bd₂ | 1450 | 310 | 25 | Y2-225M-4 | 45 | 380 | 5 | 200 | 150 | 1375 |
| 380 | 18 | |||||||||
| 450 | 13 | |||||||||
| 520 | 10 | |||||||||
| 200wfb-cd | 1450 | 350 | 55 | Y2-315S-4 | 110 | 380 | 5 | 200 | 150 | 1790 |
| 380 | 50 | |||||||||
| 420 | 45 | |||||||||
| 200wfb-cd | 1450 | 360 | 45 | Y2-280M-4 | 90 | 380 | 5 | 200 | 150 | 1660 |
| 200wfb-cd₂ | 1450 | 300 | 40 | Y2-280S-4 | 75 | 380 | 5 | 200 | 150 | 1520 |
| 330 | 36 | |||||||||
| 250WFB-AD | 1450 | 290 | 26.5 | Y2-250M-4 | 55 | 380 | 5 | 250 | 150 | 1556 |
| 330 | 25 | |||||||||
| 360 | 23.5 | |||||||||
| 250WFB-AD | 1450 | 400 | 13 | Y2-225M-4 | 45 | 380 | 5 | 250 | 200 | 1450 |
| 430 | 8 | |||||||||
| 250WFB-AD₂ | 1450 | 340 | 35 | Y2-280S-4 | 75 | 380 | 5 | 250 | 200 | 1660 |
| 360 | 33 | |||||||||
| 400 | 31 | |||||||||
| 250WFB-AD₃ | 1450 | 500 | 28.5 | Y2-280S-4 | 75 | 380 | 5 | 250 | 200 | 1660 |
| 600 | 22.5 | |||||||||
| 720 | 18 | |||||||||
| 250WFB-BD | 1450 | 350 | 45 | Y2-280M-4 | 90 | 380 | 5 | 250 | 200 | 1800 |
| 380 | 40 | |||||||||
| 450 | 37 | |||||||||
| 250WFB-BD | 1450 | 300 | 50 | Y2-280M-4 | 90 | 380 | 5 | 250 | 200 | 1800 |
| 350 | 47 | |||||||||
| 380 | 45 | |||||||||
| 250WFB-BD₂ | 1450 | 200 | 57.5 | Y2-280M-4 | 90 | 380 | 5 | 250 | 200 | 1800 |
| 260 | 55 | |||||||||
| 290 | 52.5 | |||||||||
| 250WFB-BD₄ | 1450 | 400 | 30 | Y2-280M-4 | 90 | 380 | 5 | 250 | 200 | 1800 |
| 628 | 24.5 | |||||||||
| 700 | 20 | |||||||||
| 300WFB-AD | 1450 | 500 | 26.5 | Y2-280M-4 | 90 | 380 | 5 | 300 | 250 | 1880 |
| 550 | 25 | |||||||||
| 600 | 23.5 | |||||||||
| 300WFB-AD | 1450 | 370 | 42 | Y2-280M-4 | 90 | 380 | 5 | 300 | 250 | 1988 |
| 390 | 35 | |||||||||
| 400 | 33 | |||||||||
| 430 | 31 | |||||||||
| 300wfb-ad₂ | 1450 | 600 | 30 | Y2-315L2-6 | 132 | 380 | 5 | 300 | 250 | 2058 |
| 650 | 25 | |||||||||
| 1000 | 18 | |||||||||
| 300WFB-AD | 1450 | 350 | 50 | Y2-280S-4 | 110 | 380 | 5 | 300 | 250 | 2280 |
| 400 | 47.5 | |||||||||
| 450 | 45 | |||||||||
| 300wfb-bd | 1450 | 300 | 57.5 | Y2-315S-4 | 110 | 380 | 5 | 300 | 250 | 2280 |
| 320 | 55 | |||||||||
| 345 | 52.5 | |||||||||
| 300wfb-bd | 1450 | 678 | 55 | Y2-315L2-4 | 200 | 380 | 5 | 300 | 250 | 2480 |
| 780 | 47.5 | |||||||||
| 300wfb-bd₂ | 1450 | 900 | 30 | Y2-315L1-4 | 160 | 380 | 5 | 300 | 250 | 2388 |
| 740 | 40 | |||||||||
| 590 | 50 | |||||||||
| 300wfb-bd₃ | 1450 | 600 | 57 | Y2-315L2-4 | 185 | 380 | 5 | 300 | 250 | 2400 |
| 750 | 45 | |||||||||
| 850 | 40 | |||||||||
| 978 | 35 | |||||||||
| 300WFB-CD | 1450 | 860 | 42.5 | Y2-315L2-4 | 200 | 380 | 5 | 300 | 250 | 2480 |
| 300WFB-CD | 1450 | 700 | 57.5 | Y2-355M-4 Y450S1-4 | 220 | 380 10000 | 5 | 300 | 250 | 2508 |
| 780 | 52 | |||||||||
| 890 | 45 | |||||||||
| 350WFB-AD | 1450 | 550 | 26.5 | Y2-280M-4 | 90 | 380 | 5 | 350 | 300 | 2500 |
| 600 | 25 | |||||||||
| 790 | 23.5 | |||||||||
| 350WFB-AD, | 1450 | 580 | 35 | Y2-315M-4 | 145 | 380 | 5 | 350 | 300 | 2780 |
| 690 | 33 | |||||||||
| 820 | 31 | |||||||||
| 350WFB-AD₂ | 1450 | 450 | 42.5 | Y2-315M-4 | 110 | 380 | 5 | 350 | 300 | 2630 |
| 500 | 40 | |||||||||
| 550 | 37.5 | |||||||||
| 350WFB-AD₃ | 980 | 500 | 50 | Y2-315M-6 | 145 | 380 | 5 | 350 | 300 | 2785 |
| 535 | 47.5 | |||||||||
| 590 | 45 | |||||||||
| 350WFB-BD | 1450 | 306 | 57.5 | Y5002-2 | 110 | 10000 | 5 | 350 | 300 | 2630 |
| 356 | 55 | |||||||||
| 400 | 52 | |||||||||
| 350WFB-BD | 1450 | 840 | 55 | Y2-355M-4 Y450S2-4 | 250 | 380 10000 | 5 | 350 | 300 | 2785 |
| 950 | 48 | |||||||||
| 1200 | 40 | |||||||||
| 350WFB-BD₂ | 1450 | 886 | 57.5 | Y2-355L-4 Y450S3-4 | 280 | 380 10000 | 5 | 350 | 300 | 3088 |
| 980 | 52.5 | |||||||||
| 1186 | 45 | |||||||||
| 300WFB-CD | 1450 | 860 | 42.5 | Y2-315L2-4 | 200 | 380 | 5 | 300 | 250 | 2480 |
| 300WFB-CD | 1450 | 700 | 57.5 | Y2-355M-4 Y450S1-4 | 220 | 380 10000 | 5 | 300 | 250 | 2508 |
| 780 | 52 | |||||||||
| 890 | 45 | |||||||||
| 350WFB-AD | 1450 | 550 | 26.5 | Y2-280M-4 | 90 | 380 | 5 | 350 | 300 | 2500 |
| 600 | 25 | |||||||||
| 790 | 23.5 | |||||||||
| 350WFB-AD | 1450 | 580 | 35 | Y2-315M-4 | 145 | 380 | 5 | 350 | 300 | 2780 |
| 690 | 33 | |||||||||
| 820 | 31 | |||||||||
| 350WFB-AD₂ | 1450 | 450 | 42.5 | Y2-315M-4 | 110 | 380 | 5 | 350 | 300 | 2630 |
| 500 | 40 | |||||||||
| 550 | 37.5 | |||||||||
| 350WFB-AD₃ | 980 | 500 | 50 | Y2-315M-6 | 145 | 380 | 5 | 350 | 300 | 2785 |
| 535 | 47.5 | |||||||||
| 590 | 45 | |||||||||
| 350WFB-BD | 1450 | 306 | 57.5 | Y5002-2 | 110 | 10000 | 5 | 350 | 300 | 2630 |
| 356 | 55 | |||||||||
| 400 | 52 | |||||||||
| 350WFB-BD | 1450 | 840 | 55 | Y2-355M-4 Y450S2-4 | 250 | 380 10000 | 5 | 350 | 300 | 2785 |
| 950 | 48 | |||||||||
| 1200 | 40 | |||||||||
| 350WFB-BD₂ | 1450 | 886 | 57.5 | Y2-355L-4 Y450S3-4 | 280 | 380 10000 | 5 | 350 | 300 | 3088 |
| 980 | 52.5 | |||||||||
| 1186 | 45 | |||||||||
| 350WFB-BD₃ | 1450 | 860 | 42 | Y2-315L2-4 | 200 | 380 | 5 | 350 | 300 | 2508 |
| 1050 | 35 | |||||||||
| 1180 | 32 | |||||||||
| 350WFB-CD | 1450 | 1200 | 35 | Y2-355M-4 | 220 | 380 | 5 | 350 | 300 | 2688 |
| 1320 | 32 | Y450S1-4 | 10000 | |||||||
| 350WFB-CD | 1450 | 1156 | 40 | Y2-355M-4 | 250 | 380 | 5 | 350 | 300 | 2886 |
| 1280 | 35 | Y450S2-4 | 10000 | |||||||
| 350WFB-CD | 1450 | 1128 | 45 | Y2-355L-4 | 280 | 380 | 5 | 350 | 300 | 3080 |
| 1050 | 50 | Y450S3-4 | 10000 | |||||||
| 350WFB-CD₃ | 1450 | 1000 | 57.5 | Y2-355L-4 | 315 | 380 | 5 | 350 | 300 | 3285 |
| 1200 | 50 | Y450S4-4 | 10000 | |||||||
| 350wfb-ed | 1450 | 900 | 30 | Y2-355L1-4 | 160 | 380 | 5 | 350 | 300 | 2380 |
| 1096 | 25 | |||||||||
| 350wfb-ed | 1450 | 1140 | 30 | Y2-355L2-4 | 200 | 380 | 7 | 350 | 300 | 3400 |
| 1370 | 23 | |||||||||
| 350wfb-ed₂ | 1450 | 800 | 70 | Y2-355L-4 | 315 | 380 10000 | 7 | 350 | 300 | 3780 5250 |
| 900 | 65 | |||||||||
| 1100 | 56 | |||||||||
| 350wfb-ed₃ | 1450 | 810 | 42 | Y450S4-4 | 185 | 380 | 7 | 350 | 300 | 2850 |
| 1200 | 37 | |||||||||
| 1400 | 30 | |||||||||
| 350wfb-ed₄ | 1450 | 900 | 85 | Y2-355L2-4 | 450 | 10000 | 7 | 350 | 300 | 7600 |
| 1200 | 75 | |||||||||
| 1400 | 65 | |||||||||
| 400wfb-ed | 1450 | 1140 | 30 | Y450S3-4 | 200 | 380 | 5 | 400 | 350 | 2600 |
| 1370 | 25 | |||||||||
| 400WFB-AD | 980 | 1450 | 20 | Y2-315M1-6 | 160 | 380 | 7 | 400 | 350 | 2860 |
| 1520 | 18 | |||||||||
| 1650 | 16 | |||||||||
| 1850 | 15 | |||||||||
| 400WFB-AD | 980 | 1680 | 10 | Y2-315L2-6 | 132 | 380 | 7 | 400 | 350 | 2150 |
| 400WFB-AD | 980 | 1600 | 8 | Y2-315L1-6 | 110 | 380 | 7 | 400 | 350 | 1800 |
| 400wfb-ad₃ | 980 | 2050 | 5 | Y2-315L2-6 | 145 | 380 | 7 | 400 | 350 | 1700 |
| 400wfb-bd | 980 | 1700 | 20 | Y2-355M2-6 | 185 | 380 | 7 | 400 | 350 | 2500 |
| 2085 | 15 | |||||||||
| 2300 | 12 | |||||||||
| 400wfb-bd, | 980 | 1600 | 22.5 | Y2-355M2-6 | 200 | 380 | 7 | 400 | 350 | 3650 |
| 2000 | 18 | |||||||||
| 400wfb-bd₂ | 980 | 1880 | 25 | Y2-355L-6 Y450S2-6 | 250 | 380 10000 | 7 | 400 | 350 | 3880 4960 |
| 2226 | 20 | |||||||||
| 2400 | 15 | |||||||||
| 400wfb-bd, | 980 | 1700 | 30 | YLV3551-6 Y450S3-6 | 280 | 380 10000 | 7 | 400 | 350 | 4100 5260 |
| 2506 | 20 | |||||||||
| 2750 | 16 | |||||||||
| 400wfb-cd | 980 | 2380 | 8 | Y2-355M1-6 | 160 | 380 | 7 | 400 | 400 | 2650 |
| 400wfb-cd | 980 | 1880 | 12 | Y2-315L2-6 | 145 | 380 | 7 | 400 | 400 | 2750 |
| 400wfb-cd₂ | 980 | 2280 | 12 | Y2-355M1-6 | 160 | 380 | 7 | 400 | 400 | 2860 |
| 400wfb-cd₃ | 980 | 1905 | 18 | Y2-355M2-6 | 200 | 380 | 7 | 400 | 400 | 3850 |
| 400wfb-ed | 1450 | 1100 | 60 | Y4501-4 | 355 | 10000 | 7 | 400 | 350 | 5780 |
| 1200 | 57 | |||||||||
| 1250 | 55 | |||||||||
| 400wfb-ed₁ | 1450 | 1600 | 45 | Y4501-4 | 355 | 10000 | 7 | 400 | 350 | 5780 |
| 1800 | 40 | |||||||||
| 450WFB-A | 2900 | 1745 | 110 | Y5003-2 | 850 | 10000 | 7 | 450 | 400 | 12000 |
| 2094 | 96 | |||||||||
| 2219 | 87 | |||||||||
| 450WFB-AD | 1450 | 1650 | 35 | Y2-355L-4 | 315 | 380 | 7 | 450 | 400 | 4350 |
| 2880 | 20 | Y450S4-4 | 10000 | 5560 | ||||||
| 450WFB-AD₁ | 980 | 2980 | 5 | Y2-315L1-6 | 110 | 380 | 7 | 450 | 450 | 2650 |
| 2000 | 8 | |||||||||
| 450WFB-B | 2980 | 1497 | 92 | Y5002-2 | 800 | 10000 | 7 | 450 | 400 | 11500 |
| 1872 | 85 | |||||||||
| 2246 | 73 | |||||||||
| 450WFB-BD | 980 | 2825 | 12 | Y2-355M2-6 | 200 | 380 | 7 | 450 | 450 | 3650 |
| 450WFB-BD | 980 | 2500 | 8 | Y2-315L2-6 | 132 | 380 | 7 | 450 | 450 | 2850 |
| 450WFB-CD | 1450 | 1400 | 86 | Y5001-4 | 630 | 10000 | 7 | 450 | 400 | 7600 |
| 1700 | 74 | |||||||||
| 2000 | 59 | |||||||||
| 450WFB-CD | 1450 | 1400 | 68 | Y4503-4 | 450 | 10000 | 7 | 450 | 400 | 6800 |
| 1700 | ||||||||||
| 2000 | 48 | |||||||||
| 450WFB-CD₂ | 1450 | 1400 | 46 | Y4502-4 | 400 | 10000 | 7 | 450 | 400 | 6400 |
| 1700 | 40 | |||||||||
| 2000 | 32 | |||||||||
| 450wfb-ed | 1450 | 1440 | 52 | Y4503-4 | 450 | 10000 | 7 | 450 | 400 | 6800 |
| 1600 | 50 | |||||||||
| 1740 | 46 | |||||||||
| 450wfb-ed | 1450 | 1600 | 58 | Y4505-4 | 560 | 10000 | 7 | 450 | 400 | 7200 |
| 1800 | 55 | |||||||||
| 2000 | 52 | |||||||||
| 500WFB-AD | 980 | 2300 | 25 | YLV4002-6 Y4501-6 | 315 | 380 10000 | 7 | 500 | 450 | 4500 5900 |
| 2900 | 20 | |||||||||
| 3200 | 15 | |||||||||
| 500wfb-ad₁ | 980 | 2600 | 20 | YLV3551-6 Y450S3-6 | 280 | 380 10000 | 7 | 500 | 450 | 4270 5780 |
| 2800 | 18 | |||||||||
| 3000 | 16 | |||||||||
| 500wfb-bd | 1450 | 1800 | 62 | Y4504-4 | 500 | 10000 | 7 | 500 | 450 | 7000 |
| 2100 | 58 | |||||||||
| 2350 | 50 | |||||||||
| 500wfb-bd | 980 | 1400 | 40 | YLV4002-6 Y4501-6 | 315 | 380 10000 | 7 | 500 | 450 | 4500 5900 |
| 1600 | 37 | |||||||||
| 2000 | 23 | |||||||||
| 500wfb-bd₂ | 980 | 1418 | 51 | Y5002-6 | 560 | 10000 | 7 | 500 | 450 | 9600 |
| 2000 | 47 | |||||||||
| 2600 | 40 | |||||||||
| 2850 | 30 | |||||||||
| 3000 | 20 | |||||||||
| 500wfb-bd₃ | 980 | 1760 | 55 | Y5003-6 | 630 | 10000 | 7 | 500 | 450 | 9850 |
| 2180 | 50 | |||||||||
| 2725 | 40 | |||||||||
| 3100 | 30 | |||||||||
| 3200 | 20 | |||||||||
| 500WFB-CD | 980 | 1850 | 27 | YLV3551-6 Y450S3-6 | 280 | 380 10000 | 7 | 500 | 450 | 4270 5780 |
| 2100 | 24 | |||||||||
| 2350 | 20 | |||||||||
| 500WFB-CD | 1450 | 1500 | 50 | Y4503-4 | 450 | 10000 | 7 | 500 | 450 | 7500 |
| 1900 | 45 | |||||||||
| 2200 | 40 | |||||||||
| 500WFB-CD | 980 | 2500 | 50 | Y5004-6 | 710 | 10000 | 7 | 500 | 450 | 10240 |
| 2700 | 45 | |||||||||
| 500WFB-CD | 980 | 1800 | 60 | Y5004-6 | 710 | 10000 | 7 | 500 | 500 | 10240 |
| 2000 | 55 | |||||||||
| 600wfb-ad | 980 | 3400 | 15 | YLV3551-6 | 280 | 380 | 7 | 600 | 500 | 4380 |
| 3150 | 10 | Y450S3-6 | 10000 | 5940 | ||||||
| 600wfb-ad | 1450 | 3240 | 60 | Y5003-4 | 800 | 10000 | 7 | 600 | 500 | 11900 |
| 3600 | 55 | |||||||||
| 3850 | 50 | |||||||||
| 600wfb-ad₂ | 980 | 3200 | 40 | Y5003-6 | 630 | 10000 | 7 | 600 | 500 | 9600 |
| 3600 | 37 | |||||||||
| 3850 | 32 | |||||||||
| 600wfb-ad₃ | 980 | 2700 | 32 | Y4503-6 | 400 | 10000 | 7 | 600 | 500 | 6950 |
| 3240 | 30 | |||||||||
| 3600 | 26 | |||||||||
| 600wfb-bd | 980 | 3150 | 10 | Y2-355M2-6 | 200 | 380 | 7 | 600 | 500 | 3280 |
| 3500 | 8 | |||||||||
| 3800 | 6 | |||||||||
| 600wfb-bd | 980 | 3850 | 38 | Y5601-6 | 800 | 10000 | 7 | 600 | 500 | 11900 |
| 4050 | 35 | |||||||||
| 4280 | 30 | |||||||||
| 600wfb-cd | 980 | 4020 | 5 | Y4502-6 | 355 | 10000 | 5 | 600 | 500 | 5860 |
| 600wfb-cd, | 980 | 3600 | 60 | Y5602-6 | 850 | 10000 | 5 | 600 | 500 | 13000 |
| 3850 | 55 | |||||||||
| 4080 | 50 | |||||||||
| 600wfb-cd₂ | 1450 | 3420 | 71 | Y5004-4 | 900 | 10000 | 7 | 600 | 500 | 13200 |
| 600wfb-cd₃ | 1450 | 3168 | 65 | Y5004-4 | 850 | 10000 | 7 | 600 | 500 | 12700 |
| 600wfb-ed | 1450 | 3168 | 47.4 | Y5001-4 | 630 | 10000 | 7 | 600 | 500 | 10600 |
| 800WFB-AD | 980 | 4520 | 5 | Y4502-6 | 355 | 10000 | 7 | 800 | 800 | 6400 |
| 800WFB-BD | 980 | 5480 | 5 | Y5001-6 | 500 | 10000 | 7 | 800 | 800 | 9400 |
| 800WFB-BD | 980 | 5000 | 39 | Y5002-6 | 900 | 10000 | 7 | 800 | 600 | 12900 |
| 5700 | 36 | |||||||||
| 6300 | 32 | |||||||||
| 800wfb-bd₂ | 980 | 5000 | 27 | Y5004-6 | 710 | 10000 | 7 | 800 | 600 | 10300 |
| 5700 | 24 | |||||||||
| 6300 | 22 | |||||||||
| 800WFB-CD | 980 | 6850 | 5 | Y5001-6 | 500 | 10000 | 7 | 800 | 800 | 9400 |
Saklaw ng daloy: 3.2 ~ 200m3/h Saklaw ng ulo: 20 ~ 125m Naaangkop na tem...
Saklaw ng daloy: 3.6 ~ 100m3/h Saklaw ng ulo: 20 ~ 45m Naaangkop na temp...
Saklaw ng daloy: 0.7 ~ 160m3/h Saklaw ng ulo: 5 ~ 80m Naaangkop na tempe...
Naaangkop na temperatura: -20 ° C ~ 80 ° C. Saklaw ng daloy: 3.6 ~ 100m3/h Saklaw...
Saklaw ng daloy: 1.5 ~ 110m3/h Saklaw ng ulo: 16 ~ 72m Naaangkop na temp...
Saklaw ng daloy: 3.6 ~ 1200m3/h Saklaw ng ulo: 20 ~ 125m Naaangkop na te...
We attach great importance to your letter and will reply to you as soon as possible.
Anhui Freida Pump at Valve Manufacturing Technology Co, Ltd. ay isang komprehensibong enterprise na nagsasama ng industriya at kalakalan, na dalubhasa sa paggawa ng iba't ibang kemikal na bomba, kabilang ang mga magnetic pump, centrifugal pump, submersible pump, self-priming pump, pipeline pump, at corrosion-resistant at wear-resistant pump. Ang enterprise ay gumagamit ng advanced na computer-aided engineering analysis (CFD) na teknolohiya, CNC machining technology, at mahigpit na pagsubok at quality control system upang matiyak ang mataas na kalidad ng mga produkto nito. Bilang tagagawa ng mga kemikal na bomba.
Ang aming mga produkto ay pangunahing nai -export sa maraming mga bansa at rehiyon sa buong mundo, kabilang ang Estados Unidos, Alemanya, Japan, Spain, Italy, United Kingdom, South Korea, Australia, at Canada, at nagtatag ng mga relasyon sa kooperatiba sa maraming mga halaman ng kemikal, mga halaman sa paggamot ng dumi sa alkantarilya, at mga bagong halaman ng enerhiya, kabilang ang maraming mga kumpanya ng Fortune 500. Sa pamamagitan ng tuluy -tuloy at matatag na kalidad ng produkto at serbisyo, ito ay naging isang mahalagang tagapagtustos ng bomba ng kemikal para sa mga negosyong ito sa China, na nanalo ng malawak na pagkilala sa mga pamilihan sa domestic at dayuhan.
Mga bomba na nagpapasigla sa sarili ay isang dalubhasang uri ng sentripugal pump na nagtataglay ng natatanging kakayahang i -clear ang hangin mula sa kanilang linya ng pagsipsip at pambalot n...
Tingnan ang higit paAng mga sentripugal na bomba ay ang pinaka -malawak na ginagamit na uri ng bomba sa pang -industriya, agrikultura, munisipyo, at mga aplikasyon ng tirahan. Ang kanilang katanyagan ay nagmumula sa k...
Tingnan ang higit paSa mga industriya kung saan karaniwang ginagamit ang mga kinakailangang kemikal at agresibong media, ang tibay ng kagamitan at paglaban ay nagiging mahalaga. Ang isang lubos na mahusay na solusyon ...
Tingnan ang higit paAng isang Pipeline Pump ay gumaganap ng isang mahalagang papel sa isang malawak na hanay ng mga pang -industriya at komersyal na aplikasyon. Kilala sa kahusayan, tibay, at matatag na pagganap, ang ...
Tingnan ang higit paCopyright © Anhui Freida Pump at Valve Manufacturing Technology Co, Ltd. All Rights Reserved.
Mga tagagawa ng kemikal na bomba
Bumalik Top
